316Ti 316LN Stainless Steel Plate

316Ti cold-rolled stainless steel plate is an improved product based on 316 stainless steel (0Cr17Ni12Mo2). It achieves carbon stabilization by adding titanium (Ti≥5×C%). It has excellent corrosion resistance, high temperature strength and processing performance. It is widely used in harsh environments such as chemical industry, nuclear power, and food machinery.

What are the main differences between 316Ti and 316L stainless steel plates?
Composition differences: 316Ti contains titanium (Ti) stabilizing elements, while 316L is ultra-low carbon (C≤0.03%) stainless steel.
Intergranular corrosion resistance: 316Ti generates TiC by combining titanium and carbon to avoid chromium depletion at the grain boundaries. Its intergranular corrosion resistance after welding is better than that of 316L, and it is especially suitable for scenes that require heat treatment or long-term high-temperature service.
High-temperature strength: 316Ti has better creep resistance above 600°C, while 316L focuses more on room-temperature corrosion resistance (such as seawater and dilute acid).

Specifications of  Stainless Steel 316Ti Clad Plate

Specifications	ASTM A240 and ASME SA240
Thickness in Mm	4 To 100
Width in MM	1800, 3500, 1000, 1500, 2000, 3000, 2500, 1219
Length in Mm	2440, 2000, 5800, 6000, 3000,
Finish	Cold rolled, Hot rolled, 2B, SATIN, 2D, BA, NO(8)
Surface	BA, embossed, 2B, Brush, mirror, NO.8, checkered, 8K, NO.1, sand-blast, NO.4, hair-line, etching, 2D
Hardness	Soft, Spring Hard, Quarter Hard, Half Hard, Hard, supplier and Manufacturer

AISI 316Ti Cold Rolled Sheets Equivalent

STANDARD	Werkstoff no	UNS	Japan Industrial Standard	British Standards	GOST	AFNOR	European Standards
SS 316Ti	1.4571	S31635	SUS 316Ti	320S31	08Ch17N13M2T	Z6CNDT17‐123	X6CrNiMoTi17-12-2

AISI 316TI Plate Chemical Composition

Grade	Carbon	Manganese	Silicon	Phosphorous	Sulfur	Chromium	Nitrogen	Nickel	Titanium
316Ti stainless steel	0.08 maximum	2.0 maximum	1.0 maximum	0.045 maximum	0.030 maximum	17.00 – 19.00	0.10 maximum	9.00 – 12.00	5(C+N) – 0.70 maximum

ASTM A240 TP316Ti Sheet Mechanical Behaviour

Melting Point	Density	Tensile Strength	Elongation	Yield Strength
1457°C	8.0 gram per CM	Psi=75000, MPa=515	35 %	Psi=30000, MPa=205



GNEE's main products include stainless steel coils, stainless steel plates, stainless steel pipes, and products are mainly exported to Southeast Asia, North Africa and the Middle East markets, such as South Korea, Vietnam, Thailand, Myanmar, the Philippines, Singapore, Jordan, Dubai and Kuwait.
Our strategic raw material suppliers include TISCO, Baosteel, Ansteel, etc. All raw materials are strictly inspected before storage to ensure the quality of raw materials and finished products.

Cut-to-length & Slitting
Cutting
Grinding
Beveling
Machining
Heat Treatment
Sandblasting & Painting
Prefabrication

1. Q: Can we visit your factory?
A: Warmly welcome. Once we have your schedule, we will arrange the professional sales team to follow up your case.
2. Q: Can you provide OEM/ODM service?
A: Yes. Please feel free to contact us for more detail discussion.
3. Q: How is your Payment Term?
A: We prefer TT
4. Q: Can you provide sample?
A: Yes, for regular size of samples, it's for free but buyer need to pay freight cost.
